Yamaha YBR 125 2014 - 2015 models








Yamaha YBR 125 workshop manual

Buy now

The Yamaha YBR 125 2014 model




Eager to please, this punchy 4-stroke will happily propel you around city streets with its smooth fuel injection and five-speed gearbox. For 2014 a new mini cowling not only gives the YBR a sleeker look, together with the tank covers it improves rider comfort levels by providing added weather protection.
Benefiting from a light, diamond-shaped chassis, the YBR125 offers controlled handling and effective suspension for a reassuring ride. Braking comes courtesy of a front disc and rear drum brake and a sculpted dual seat and passenger grab rails guarantees comfort for both rider and pillion.
Built for easy-going performance and reliability, the YBR125 won't let you down.
Reliable, fun performance
Fuel-injected, air-cooled 125cc engine
Lightweight diamond-shaped steel chassis
New stylish mini front cowling
Clear analogue instrument panel with RPM meter
Roomy, dual seat with luggage rack .

Economical 4-stroke, fuel-injected engine

Economical 4-stroke, fuel-injected engine

The YBR125 runs a 4-stroke, fuel-injected engine bringing the dual benefits of cutting back on emissions and delivering a smooth throttle response.
Lightweight, diamond-shaped chassis

Lightweight, diamond-shaped chassis

Weighing in at 125 kg, the diamond-shaped steel chassis of the YBR125 is rugged yet lightweight. The combination delivers assured road handling and easy steering, as well as great suspension for a more comfortable ride.
Smooth braking

Smooth braking

A powerful 245 mm single-disc front brake works in tandem with a 130 mm drum rear brake to deliver smooth, effective stopping. Whatever the conditions, riders can put their faith in Yamaha's advanced engineering.
Roomy, dual seat and mini cowling

Roomy, dual seat and mini cowling

Whether you're riding solo or with a passenger, the sculpted dual seat offers plenty of comfort while the new mini cowling improves rider weather protection. Grab rails on the rear luggage carrier mean you can both relax and enjoy the journey.

Alloy wheels

The YBR125's 5-spoke cast alloy wheels don't just look good, by minimising unsprung weight they contribute to the bike's lightweight and agile handling.

Full statistics

Engine type
4-stroke, air-cooled, SOHC, Forward-inclined single cylinder, 2-valves
Displacement
124cc
Bore x stroke
54.0 mm x 54.0 mm
Compression ratio
10.0 : 1
Maximum power
7.5 kW (10.0PS) @ 7,800 rpm
Maximum torque
9.6 Nm (0.98 kg-m) @ 6,000 rpm
Lubrication system
Wet sump
Clutch type
Wet, multiple-disc coil spring
Fuel system
Electronic Fuel Injection
Ignition system
TCI
Starter system
Electric
Transmission system
Constant Mesh, 5-speed
Final transmission
Chain

Chassis


Frame
Diamond Shaped
Front suspension system
Telescopic forks
Front travel
120 mm
Caster angle
26º
Trail
90 mm
Rear suspension system
(monocross)
Rear travel
105 mm
Front brake
Hydraulic single disc, Ø 245 mm
Rear brake
Drum, Ø 130 mm
Front tyre
2.75-18 42P
Rear tyre
90/90-18 M/C 57P

Dimensions


Overall length
1,985 mm
Overall width
745 mm
Overall height
1,100 mm
Seat height
780 mm
Wheel base
1,290 mm
Minimum ground clearance
160 mm
Wet weight (including full oil and fuel tank)
126 kg
Fuel tank capacity
13 litres
Oil tank capacity
1.2 litres
