Yamaha YBR 125 Front and Rear Brakes Common Problems










Yamaha YBR 125 Brake Problems




Yamaha YBR 125 workshop manual

Buy now







see also our  brake bleed post






Yamaha YBR 125 front and rear brake , i have not had any problems whatsoever with mine so far , but problems will occur eventually  .

Always check you fluid and pads/shoes regular and change fluid - see the pre ride checks
post here and the routine maintenance post here .

here some common problems etc that can occur in any motorcycle braking system .


Yamaha YBR 125 Brake Problems
                         Yamaha YBR 125 Brake Problems


brakes are spongy or do not hold

- air in brake line or fluid leak
-pads/discs worn
-contaminated pads ie oil/grease
-deteriorated brake fluid
-master cylinder faulty/worn
-disc warped

brake does not hold

-brakes incorrectly adjusted
-brake shoes worn
-leak loss of fluid in braking system

Vibration

-disc warped
-wheel axle bent
-brake caliper bolts loose
-wheel warped/damaged
-wheel bearing wear or damaged
-brake drum out of shape

Brake drag

-master cylinder piston seized
-levers or pedals stuck seized stiff
-caliper pistons or assembly seized
-brake pads not installed correct or damaged or foreign object present
-fluid contamination
-brake shoe springs
-brake shoe mechanism seized

Yamaha YBR 125 Brake Problems

Yamaha YBR 125 Brake Problems

Yamaha YBR 125 Brake Problems

Yamaha YBR 125 Brake Problems

Yamaha YBR 125 Brake Problems

Yamaha YBR 125 Brake Problems
